Fabrics for Special Impregnations
Gavazzi technical textiles for special impregnations
Gavazzi celebrates 140 | Download the interactive pdf ebook of the book of 140 years of Gavazzi Tessuti Tecnici
The constant research aimed at satisfying a market that requires products of the highest quality has allowed Gavazzi to create a wide range of fabrics that are used in leading technical sectors where quality and performance are the first evaluation criteria.
Fiberglass weaving expertise
Over the years Gavazzi has specialized in weaving fabrics in glass fiber (6 and 9 micron), aramid fiber (meta and para) and hybrids.
The production of these items is subject to rigorous quality controls at all stages, from the selection of the yarns to the warping and weaving. In addition, caramelization, washing or chemical primer treatments can be provided to improve compatibility with the formulations used by our customers (PTFE, silicone, PVC etc.).
The company is constantly looking for partnerships with its customers with the aim of promoting quality technological innovation.
Use
Conveyor belts
Membranes for Architecture
Filtration
Chemical resistance and compatibility
Ballistic protection
Insulation
Recommended products
| ARTICLE | WEIGHT | WARP YARNS (yarns number/cm) | WEFT YARNS (yarns number/cm) | WARP YARN | WEFT THREAD | WEAVE | TECHNICAL DATA SHEET |
|---|---|---|---|---|---|---|---|
| 0128G | 200 g/m2 ± 5% | 17 | 12 | EC7 22x3 | EC7 22x3 | Plain |  |
| 0141G | 295 g/m2 ± 5% | 12,6 | 8,3 | EC9 68x2 | EC9 68x2 | Plain | |
| 0142G | 393 g/m2 ± 5% | 7,65 | 6,6 | EC13 272x1 | EC13 272x1 | Plain | |
| 0162G | 400 g/m2 ± 5% | 11 | 6,3 | EC7 22x2x5 | EC7 22x2x5 | Plain | |
| 0260G | 610 g/m2 ± 5% | 10,5 | 5,4 | EC9 136x2 | EC9 136x4 | Plain | |
| 0305K-WW | 260 g/m2 ± 5% | 12 | 11 | Kevlar 110 | Kevlar 110 | Plain | |
| 0342G | 360 g/m2 ± 5% | 5,1 | 2,8 | EC9 136x3 | EC9 136x3 | Leno | |
| 0400GI | 400 g/m2 ± 5% | 18,6 | 10,5 | EC9 136x1 | EC9 136x1 | Plain | |
| 0440GI | 415 g/m2 ± 5% | 18,6 | 11 | EC9 136x1 | EC9 136x1 | Satin Turc 1/3 | |
| 0494K | 260 g/m2 ± 5% | 5,1 | 4,7 | Kevlar 121x2 | Kevlar 121x2 | Plain | |
| 0533KI | 305 g/m2 ± 5% | 8,8 | 8,3 | Kevlar 167 | Kevlar 167 | Plain | |
| 0690G | 1080 g/m2 ± 5% | 9,56 | 4,66 | EC6 134x4 | EC6 134x4x2 | Panama | |
| 0707G | 610 g/m2 ± 5% | 10,6 | 5,5 | EC6 134x2 | EC6 134x4 | Weft rib | |
| 0713K-WW | 280 g/m2 ± 5% | 12 | 12 | Kevlar 110 | Kevlar 110 | Plain | |
| 1054G | 203 g/m2 ± 5% | 14,3 | 15 | EC7 22x3 | EC7 22x3 | Plain | |
| 1142GI | 290 g/m2 ± 5% | 12,6 | 8,3 | EC9 136x1 | EC9 136x1 | Plain | |
| 1528G | 200 g/m2 ± 5% | 17 | 12 | EC9 34x2 | EC9 34x2 | Plain | |
| 1535GI | 203 g/m2 ± 5% | 17,3 | 12,6 | EC9 34x2 | EC9 34x2 | Plain | |
| 1538G-C | 203 g/m2 ± 5% | 17,3 | 13 | EC6 33x2 | EC6 33x2 | Plain | |
| 1564G | 410 g/m2 ± 5% | 8 | 6,7 | EC9 136x2 | EC9 136x2 | Plain | |
| 1566G | 450 g/m2 ± 5% | 8 | 8 | EC9 136x2 | EC9 136x2 | Plain | |
| 1571G | 350 g/m2 ± 5% | 3,1 | 1,2 | EC9 136x5 | EC9 136x4x2 | Leno | |
| 1583GI | 565 g/m2 ± 5% | 21,2 | 18,8 | EC9 68x2 | EC9 68x2 | Plain | |
| 1584G | 850 g/m2 ± 5% | 16,1 | 13,8 | EC9 136x2 | EC9 136x2 | Satin 8 | |
| 1586G | 480 g/m2 ± 5% | 6,5 | 4,7 | EC9 136x3 | EC9 136x3 | Plain | |
| 1589G | 410 g/m2 ± 5% | 5 | 4,7 | EC9 136x3 | EC9 136x3 | Plain | |
| 1590G | 320 g/m2 ± 5% | 4 | 2 | EC9 136x3 | EC9 136x5 | Leno | |
| 1595G | 375 g/m2 ± 5% | 3,2 | 1,5 | EC9 136x4 | EC11 204x6 | Leno | |
| 1596G | 350 g/m2 ± 5% | 4 | 2 | EC9 136x3 | EC9 136x6 | Leno | |
| 2545G | 400 g/m2 ± 5% | 11 | 8 | EC9-68x3 | EC9-68x3 | Plain | |
| 3010G | 325 g/m2 ± 5% | 4 | 3,8 | EC9 136x3 | EC9 136x3 | Plain | |
| 3718G | 275 g/m2 ± 5% | 6 | 5 | EC9 68x4 | EC9 68x3 | Plain | |
| 3719G | 275 g/m2 ± 5% | 6 | 4,8 | EC9 68x4 | EC9 68x3 | Plain | |
| 3724G | 1100 g/m2 ± 5% | 9,4 | 9,4 | EC9 136x4 | EC9 136x4 | Panama | |
| 3745G | 615 g/m2 ± 5% | 11 | 10,5 | EC9 136x2 | EC9 136x2 | Weft rib | |
| 3784G | 845 g/m2 ± 5% | 16,1 | 14 | EC9 136x2 | EC9 136x2 | Satin 7 | |
| 4055G | 575 g/m2 ± 5% | 9,9 | 7 | EC9 136x2 | EC9 136x3 | Weft rib | |
| 4110G | 415 g/m2 ± 5% | 10,8 | 8,8 | EC6 66x3 | EC6 66x3 | Plain | |
| 4285G | 335 g/m2 ± 5% | 8,5 | 3,5 | EC 9 68x3 | EC9 136x3 | Leno | |
| 4358G | 380 g/m2 ± 5% | 4 | 2 | EC9 136x3 | EC9 136x7 | Leno | |
| 4415G | 620 g/m2 ± 5% | 16 | 15,3 | EC9x2 + inox | EC9x2 + inox | Satin 8 | |
| 4480G | 300 g/m2 ± 5% | 5,3 | 5,1 | EC9 68x4 | EC9 68x4 | Plain | |
| 4711GK | 415 g/m2 ± 5% | 4 | 1,6 | Twaron 322 | EC9 136x2x6 | Leno | |
| 4901K | 170 g/m2 ± 5% | 3,8 | 2 | Twaron 121x2 | Twaron 322 | Plain | |
| 4938G | 375 g/m2 ± 5% | 2,5 | 1,4 | EC9 136x5 | EC9 136x5x2 | Leno | |
| 4983G | 410 g/m2 ± 5% | 4 | 1,7 | EC 9 136x3 | EC9 136x5x2 | Leno | |
| 4985G | 335 g/m2 ± 5% | 3,2 | 1,4 | EC 9 136x3 | EC9 136x5x2 | Leno | |
| 5115K | 308 g/m2 ± 5% | 4 | 2 | Twaron 121x2 | Twaron 121x8 | Leno | |
| 5138K | 240 g/m2 ± 5% | 7,5 | 2 | Twaron 121 | Twaron 322x2 | Leno | |
| 5175G | 270 g/m2 ± 5% | 7,8 | 3,7 | EC 9 68x2 | EC9 136x3 | Leno | |
| 5222K | 300 g/m2 ± 5% | 6 | 2,8 | Kevlar 121x2 | Kevlar 121x3 | Leno | |
| 5233GK | 415 g/m2 ± 5% | 4 | 1,6 | Twaron 322 | EC9 136x6x2 | Leno | |
| 5258GI | 405 g/m2 ± 5% | 18,6 | 11 | EC9 136x1 | EC9 136x1 | Double satin turkish | |
| 5269K | 180 g/m2 ± 5% | 3,8 | 2 | Twaron 121x2 | Twaron 121x3 | Leno | |
| 5270GK | 435 g/m2 ± 5% | 3,4 | 2 | Twaron 121x2 | EC9 136x2x6 | Leno | |
| 5277G | 605 g/m2 ± 5% | 11 | 6,7 | EC9 136x2 | EC9 136x3 | Plain | |
| 5280KI | 230 g/m2 ± 5% | 3,7 | 3 | Twaron 121x2 | Twaron 121x3 | Leno | |
| 5354G | 600 g/m2 ± 5% | 4 | 3 | EC9 136x3 | EC9 136x5x2 | Mix Plain and Leno | |
| 6010G | 240 g/m2 ± 5% | 22 | 7,3 | SC9 66x1 | SC9 66x2 | Plain | |
| 6171G | 166 g/m2 ± 5% | 12,6 | 12,6 | SC9 66x1 | SC9 66x1 | Panama | |
| 7526G | 296 g/m2 ± 5% | 11 | 10,2 | EC9 68x2 | EC9 68x2 | Plain | |
| 7544G | 620 g/m2 ± 5% | 11 | 5,5 | EC9 136x2 | EC9 136x4 | Weft rib | |
| 7545G | 630 g/m2 ± 5% | 11 | 5,5 | EC9 136x2 | EC9 136x4 | Plain | |
| 7628GA76 | 203 g/m2 ± 5% | 17,6 | 12 | EC9 68x1 | EC9 68x1 | Tela | |
| 7628GI-T | 203 g/m2 ± 5% | 17,6 | 12 | EC9 68x1 | EC9 68x1 | Plain | |
| 7661G | 170 g/m2 ± 5% | 12 | 12,5 | EC9 68x1 | EC9 68x1 | Plain | |
| 9117G | 195 g/m2 ± 5% | 7 | 7 | EC9 68x2 | EC9 68x2 | Plain | |
| 9213G | 1150 g/m2 ± 5% | 16 | 10 | ET9 136x3 | ET9 420x1 | Plain | |
